Project Overview
In modern residential home plans construction, innovation plays a crucial role in enhancing both performance and efficiency. This single-storey BIM residential building, of area 1862 sq. ft. in Florida, USA showcases how advanced engineering and thoughtful design can redefine conventional building practices. Building information modelling services from LOD 100 to LOD 500 in USA for both light gauge steel and timber framed structures
- Project Type: Residential Building
- Area: 1862 sq. ft.
- Storey: Single Storeys
- Roof Type: Mono Roof
Scope of Work
Our team delivered a comprehensive set of services, ensuring precision and seamless execution at every stage:
- Engineering
- 3D Modelling
- Detailing
- Permit Sets
- CNC Production Files
Innovative Design Approach
One of the standout features of this single storey house design project is the strategic departure from traditional construction methods.
Instead of relying on conventional truss systems, roof panel system was adopted to enhance structural efficiency. This approach not only streamlined the design but also improved load distribution and overall performance of the roofing system.
To address long unsupported spans, a back-to-back joist profile was implemented. This innovative solution significantly strengthened the structure by:
- Improving load-bearing capacity
- Minimizing deflection
- Reducing overall steel consumption
The result is a structure that is both economically efficient and structurally robust.
Software and Machine
The success of this project was driven by advanced tools and precision manufacturing:
These technologies enabled accurate detailing, reduced errors, and ensured smooth coordination between design and production.
How does a back-to-back joist profile improve Light Gauge Steel Frame (LGSF) structures?
A back-to-back joist profile increases the strength and stiffness of long-span framing, reduces deflection, enhances load-bearing capacity, and minimizes overall steel consumption.
What services did UBC provide for this residential BIM project in Florida, USA?
UBC delivered end-to-end services including structural engineering, 3D BIM modelling, detailing, permit sets, and CNC production files for seamless manufacturing and construction.https://ubcbim.com/single-family-residential-building.html
Which software and machine were used for this Light Gauge Steel residential project?
The project was designed and detailed using Vertex BD software, and manufacturing files were generated for the Howick machine to ensure precision, accuracy, and efficient production.
Does UBC provide BIM and engineering services for LGSF and timber-framed residential buildings in the USA?
Yes, UBC offers comprehensive BIM services from LOD 100 to LOD 500, including pre-bid packages, 3D BIM models, bill of materials, detailing, permit sets, and engineering calculations for Light Gauge Steel, Cold Formed Steel, and timber-framed structures across the USA.
Conclusion
This project is a perfect example of how modern engineering techniques and digital tools can optimize prefabricated steel residential construction. By integrating innovative framing solutions and leveraging advanced software, the project achieved a balance between efficiency, durability, and cost-effectiveness.
As the construction industry continues to evolve, such forward-thinking approaches will play a key role in shaping the future of residential home designs. UBC offers permit sets, pre-bid packages with 3D BIM model along with bill of materials for project cost estimation, modelling and detailing services, engineering calculations for light gauge steel/cold formed steel/ timber framed building structures in Florida, USA.
