Project of the Month
Project type: Residential Building
Area:3930sft
Storey:1-storey
Roof: Mono and hip roof
Scope of Work: Engineering
Modelling
Detailing
CNC Production Files
Shop Drawings
Project Description:
This project showcases an innovative Residential construction that includes a basement, first floor and roof using Light Gauge Steel Framing (LGSF) walls, we have done floor framing system, roof framing system, wall framing system.
Initially, we received the architectural, HVAC plans from the client. Our dedicated team then executed comprehensive engineering, modelling, and detailing in accordance with these plans, leading to the submission of well-prepared production files and permit sets.
A standout feature of this project is the striking hip roof and Mono Roof designed using LGSF In Florida, USA that enhances both aesthetics and functionality. Furthermore, a significant achievement of our team was the seamless conversion of Vertex CNC files to Arkitech machine files, which streamlined our production process and improved overall project efficiency.
Following SIMPSON STRONG-TIE Connectors were meticulously integrated into the project to fortify structural cohesion and compliance with engineering standards.
Software: Vertex BD
Machine Used : Arkitech Advanced Construction Technologies
Industry Insights
When a wall of fire swept through the hillside neighborhood of Pacific Palisades in early 2025, it left behind a trail of destruction. Entire blocks of timber-framed homes were reduced to ash. One house, built in 2021, offers a striking example of resilience in the face of extreme conditions. Read More
Typical Connection – Powder-Actuated Pin (PDPAT)
In this project, a Powder-Actuated Pin (PDPAT) was used as a typical fastening solution to securely connect structural components to concrete, structural steel, and CMU (Concrete Masonry Unit). This connection method provides a fast, efficient, and reliable installation while maintaining the required structural performance.
Connection Highlights
- Used to fasten framing components directly to concrete, steel, and CMU substrates.
- The hardened-steel pin with a top-hat assembly ensured accurate alignment and efficient installation using a powder-actuated fastening tool.
- The selected pin length provided the required embedment depth after accounting for the thickness of the connected material.
- Installed using powder-actuated tool systems, enabling rapid installation and improved on-site productivity.
- Chosen for its code-compliant performance and dependable fastening capability in structural applications.
